Mixer Machine
Mixer : PVC resin (vertical, horizontal)
Mixer PVC
รายละเอียดสินค้า
| Model / Parameter | Volume (L) | Effective volume (L) | Speed (r/min) | Motor power (Kw) | Water consumption (T/h) | Heating Power Cooling medium | Unloading method |
|---|---|---|---|---|---|---|---|
| SRL-Z50/100 | 50/100 | 32/75 | 510/1013/118 | 7/11/7.5 | 3 | 2kw/water | Manually operationl air-powered |
| SRL-Z100/200 | 100/200 | 75/130 | 650/1300/130 | 14/22/11 | 5 | 6kw/water | Air-powered |
| SRL-Z200/500 | 200/500 | 150/320 | 480/1000/110 | 30/42/11 | 5.8 | 6kw/iwater | Air-powered |
| SRL-Z300/600 | 300/600 | 225/380 | 480/960/100 | 40/55/11 | 6 | 9kwwater | Air-powered |
| SRL-Z500/1000 | 500/1000 | 375/640 | 410/830/15 | 47/67/15 | 7 | 9kw/water | Air-powered |
